Other Tools


EXPANSION/COMPACTION JOINT

HYDRO TRIP 2-rid.png

HYDRO TRIP SUB

CIM FULL 3-rid.png

CHEMICAL INJECTION MANDREL

CIM is a tubing retrievable system, with a chemical injection valve fixed on the mandrel, used for continuous chemical injection to the well. Injection valve is independent of mandrel loading, all connections externally pressure testable.

SWIVEL SUB 15.png

SWIVEL SUB

Enables surface connections to be in one place while the work string is rotated and moved vertically.

DEFORMATION TOOL

WIRE LINE ADAPTER KIT


PULLING/RUNNING PRONG

Used in conjunction with a X Line Running Tool to manipulate "X" equalizing assemblies.


RUNNING TOOL

Tool which is used in the placement or setting of downhole equipment such as permanent packers or plugs. Capable of being retrieved after the working/setting process.

TEXT FIXTURES (TEST CAP/TEST PLUG)

Test Fixtures are used to check the pressure rating of the Testing Equipment.

STANDING VALVE

LOCK ADAPTER


LOCK MANDREL

The lock mandrel is a downhole completion device, run and retrieved by slick line and anchored in the Landing Nipple within the tubing string, provide a setting point for flow-control equipment such as valves chokes and plugs. Almost unlimited locations for setting and locking subsurface flow controls, has extra Large ID for higher flow volumes.


SLIDING SLEEVE DOOR

SSD are used to isolate flow from one or more reservoir zones or to regulate pressure between zones. Regulates the flow of fluid into a well during  hydraulic fracturing or proppant fracturing process.

SLOT TOOL

PUMP OUT PLUG
