Single components and CP products
LIFTING SUB/ PAD EYE/ DOUGHNUT TYPE
A component connected to the top of a tool assembly to lift vertically. Allows the rig elevators to lift the assembled tool string safely
Landing nipples are included in most completions at pre-decided intervals to enable the installation of flow-control devices, such as plugs and chokes. Large bore allows maximum flow rate. Great extent of versatility to lessen completion and production maintenance cost.
It can have dual application of centralising and drifting well bore. The fluted design allows to fluid to pass with minimum obstruction.
NO GO LOCATOR
Main application been to prevent downward movement, it has a lock sholder to lock itself.
POLISHED BORE RECEPTACLES
Along with seal assembly it provides separation function. And also provides stroke movement for compensation of any tubing movements during production or well treatment.
SEAL UNIT SUB
Acts as the part of tubing string which hosts the seals which sit inside the packer seal bore.Used in multiple numbers (in unison) to provide for contingency sealing over a longer stroke length thereby accommodating for tubing movements as well.
SEAL BORE EXTENSION
Gives adequate seal bore length in order that extensive seal assemblies can accommodate tubing movement while being inside the seal bore. Facilitates and ensures proper sealing even when accommodating tubing movement.
SPACER SUB/ SEAL SPACER SUB
Mainly used in application to provide space between seal units.
The tool provides a larger ID below the packer to secure the milling tool. The extensive ID is useful when a packer milling and retrieving tool is used. Provides to engage the milling and retrieving tool thereby supporting the hanging weight of the packer string.
Used a plug at the end of the string for various operations. It has a smooth round finish making it easy for entry.
During downhole operation bull nose comes with a port opening for jetting/cement pumping operation.
Placed directly facing perforations in dual completions/ straight below the tubing hanger in sand fracture situations. The wall of the tool is treated to withstand the jetting force that may result in the proximity of the perforations from incoming fluids.
Heavily walled component installed in areas where turbulence is expected. Flow couplings are usually installed above and below completion components, such as landing nipples, SSD, etc., to reduce the effect of turbulence.
WIRE LINE ENTRY GUIDE
Fitted on the bottom end of the string which allow easier and safe entry of tools.
MULE SHOE / HALF MULE SHOE
Guides the tool assembly (tubing) into the packer seal bore.
Having the (Half) internal taper allows easy insertion of tubing string into the packer bore.
CROSSOVERS & COUPLINGS
Used as an adapter to connect tubular sections such as casing, tubing, drill pipe. It comes in different configurations for connecting different size and type of threads. Example STUB-ACME, API connections, Premium connections like VAM, VAGT, JFE Bear, Tenaris, Hunting.
Capable of connecting various sizes, ensures performance and tubing integrity is maintained appropriately.
